MGS 0802X

Compact 8-port switch with 2 SFP ports. L2+ for small business/cameras, 20Gbps.
Apply Now
The MGS 0802X switch is an affordable yet feature-rich switch. Despite its compact size, it supports a wide range of management functions: VLAN, QoS, port mirroring, link aggregation (LACP), and advanced security mechanisms.

The presence of two SFP slots allows for a fiber-optic uplink. A passively cooled (fanless) option is available for operation in environments where low noise levels are critical.


Technical Specifications

Product type: Managed switch
Switch layer: L2+
Other ports: 2 x SFP 1 Gbps
Uplink ports: 1G SFP
Switching capacity: 20 Gbps
Forwarding rate: 14.88 Mpps
MAC address table: 8K entries
Jumbo Frame: 9216 bytes
Standards: IEEE 802.3af/at, 802.3az, 802.1X, 802.1q, 802.1p, 802.1d, 802.1w, 802.3ad
Security: ACL (L2-L4, IPv6), 802.1X, ARP spoofing protection, DoS attack protection, Port Security, Radius/TACACS+
Management: Web, CLI (Console, Telnet, SSH), SNMP
Power: AC 100-240V, 50/60Hz
Power supply: 150 W (built-in)
Cooling: 1 fan
  • Dimensions (DxWxH): 280 x 180 x 44 mm
Technical support at all stages of deployment and operation

What's in the Box

  • MGS 0802PX Switch × 1

  • Power Cord × 1

  • Rubber Feet × 4

  • Console Cable (RJ45 to DB9) × 1

  • Rack Mount Kit (brackets) × 2

  • User Manual × 1

  • Mounting Screws × 8

Documentation

User manual
Product datasheet
